● 16 ranges in 6 functions
● Overload protection
● AC/DC voltage measurement up to 500V
● DC current measurement up to 250mA
● Resistance measurement up to 1MΩ
● Battery test 1.5V and 9V
● Fuse: F500mA/250V
● Input impedence: 2KΩ/ VDC/ VAC
● Accessories included: 1.5V battery, elastomer boot, English manual, full blister
SPECIFICATIONS
DC Voltage 2.5/10/50/250/500V (±5.0% f.s)
AC Voltage 10/50/500V (±5.0% f.s)
DC Current 0.5m/10m/250mA (±5.0% f.s)
Resistance 10K/1MΩ (±5.0% of full arc)
Battery test 1.5V (110mA), 9V (9mA)
dB measurement: -10~56 (0dB 1mW/600Ω)
Operating temperature 0~40℃ (32~104oF) at RH<80%
Dimensions 155x88x49mm
Weight Approx. 288g included battery
Measurement Category EN61010-1,CAT II,600V
The meter is in two forms, one is a high precision laboratory testing equipment and the other is for the primary family use.
We hope the user to develop a good habit in using analog multimeter,which is callled "jump connection" (the so-called jump connection is with quick wire touching the wiring or with quick opening and closing switch),a very important method for analog multimeter.When the voltage in the circuit cannot be determined, connect one end into the circuit and the other end with jump connection method and then leave quickly, observe the pointer's movement in time..
User should be sure of understanding the full content of the user manual before using.
Always remember: make sure the range is in the right position in the first place, then check the test leads.
Read the SAFETY CAUTION, Maintainance and repair in the user manual.
